Includes
Carbide Blade
Users Guide
Blade Wrench
Material Clamp
Integrated XPS cross cut positioning system provides adjustment free cut line indication for better accuracy and visibility
Capacity to cut up to 3 5/8in nested crown and 3 1/2 base vertically
Will cut 2x8 laying flat
Adjustable stainless steel miter detent plate with 11 positive stops improves productivity and ensures cutting accuracy
Oversized bevel scale makes bevel angle adjustments accurate and easy
Compact, lightweight design (30 bs.) allows for easy transport and storage
Cam lock miter handle delivers quick and accurate miter angles
Precise miter system and machined base fence support optimize durability and cutting accuracy
Specifications
Blade Diameter 7-1/4in
Voltage 20V
No Load Speed 3750rpm
Arbor Size 5/8in
Vertical Capacity\: Baseboard Against Fence 3-1/2in
Vertical Capacity\: Crown Molding Vertically Nested 3-5/8in
Horizontal Capacity\: Baseboard Lying Flat 8in
Horizontal Capacity\: Crown Molding Lying Flat 8in
45° Bevel Cut Capacity (dimensional lumber) 1.5 x 8in
90° Cross-Cut Capacity (dimensional lumber) 8in
90° Cross-Cut Capacity (Max Width) 8in
45° Miter Cut Capacity (Max Height) 2in
45° Miter Cut Capacity (Max Width) 5.5
Tool Weight 30lbs
