Delivers whisper-quiet operation with its unique muffler design and two-layer enclosure for sound deadening.
Specifications
Generator Type: Inverter
Maximum AC Output (Watts): 3000
AC Voltage Available: 120
Maximum Continuous AC Output (Watts): 2800
Max. Rated AC Amperage @ 120 V / 240 V: 23.3 / -
Ground Fault Circuit Interrupter (GFCI): N/A
Frequency (Hertz): 60
Automatic Voltage Regulator: Standard
DC Output Volts / Amps: 12 / 8.3
Common Duplex Receptacle Specifications: 23.3 amps/120 VAC continuous is available as combined total from these two AC receptacles. Maximum of 20 amps is available from a single receptacle.
DC Receptacle Specifications: 8.3 amps/12 VDC is available from this receptacle. Important Note: AC and DC output cannot be used simultaneously. DC system uses floating N (Neutral) type.
DC Charging Cable: Standard
High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications: This receptacle (NEMA # L5-30R) will supply 23.3 amps at 120 VAC continuously.
Engine
Engine Type: Honda GX200T2 OHV, 4-stroke, air-cooled
Displacement: 196 cc
Starting System: Electric/recoil
Low Level Oil Alert System: Standard
Auto Throttle: Eco-Throttle standard
Remote Start Capability: No
Fuel Tank Capacity: 13 liters (2.86 Imp. gal.)
Additional Information
Transport Wheels: Optional wheel kits: 4-wheels same size: P/N 06423-ZS9-T30 4-wheels, large RR & front swivel/ locking wheels: P/N 06424-ZS9- 000AH 2-wheels with telescoping handles: P/N 06425-ZS9-020AH
Lifting Hook: N/A
Battery: Standard (P/N 31500-HN1-003AH)
Approximate Running Time (hrs.) / Tankful: 7.2** / 20***
Rated Fuel Consumption (liters/hr.): 1.78**
Noise Level dB(A) (1.5 m to 7 m): 58** / 48***
Length (Without Handles and Wheels): 655 mm (25.8 in.)
Length (With Handles and Wheels): N/A
Width (Without Handles and Wheels): 445 mm (17.5 in.)
Width (With Handles and Wheels): N/A
Height (Without Lift-Hook): 555 mm (21.9 in.)
Height (With Lift-Hook): N/A
Dry Weight: 59 kg (130 lbs.)
Cold Climate Technology: Standard
