Offers high output for home back up power or RV’s and stable electricity for sensitive electronic devices.
Features
Electronic Fuel Injection (reduces maintenance associated with carburetors and fuel storage issues)
7000 Watts (45.8/22.9 A) 120/240 VAC of Honda inverter power
Super Quiet - 60 dB(A)
Large capacity fuel tank, 19.2 liters
Eco-Throttle standard - Runs up to 12.1 hours at 1/2 load on 19.2 liters of fuel
Convenient Electric Start with Push button Switch (battery included) and Recoil as back-up
Wheel Kit Standard with Positive Lock Folding Handle
Specifications
Generator Type: Dual inverter
Maximum AC Output (Watts): 7,000
AC Voltage Available: 120 / 240
Maximum Continuous AC Output (Watts): 5,500
Max. Rated AC Amperage @ 120 V / 240 V: 45.8 / 22.9
Ground Fault Circuit Interrupter (GFCI): N/A
Frequency (Hertz): 60
Automatic Voltage Regulator: PWM (Pulse Width Modulation)
DC Output Volts / Amps: N/A
Common Duplex Receptacle Specifications: 40 amps/120 VAC continuous is available as combined total from these two AC receptacles. Maximum of 20 amps available from a single receptacle.
DC Receptacle Specifications: N/A
DC Charging Cable: N/A
High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications: This receptacle will supply 30 amps at 120 VAC continuously. This receptacle will supply 22.9 amps at 240 VAC and 45.8 amps at 120 VAC continuously.
Engine
Engine Type: Honda GX390T2 OHV, 4-stroke, air-cooled
Displacement: 389 cc
Starting System: Electric/recoil
Low Level Oil Alert System: Standard (LED display)
Auto Throttle: Eco-Throttle standard
Remote Start Capability: Optional
Fuel Tank Capacity: 19.2 liters (4.22 Imp. gal.)
Additional Info
Transport Wheels: 2-wheel kit standard
Lifting Hook: Optional (P/N 06531-Z11- E00ZA)
Battery: Standard (P/N 31500-MCR-D02AH)
Approximate Running Time (hrs.) / Tankful: 6.5/ 18
Rated Fuel Consumption (liters/hr.): 2.95
Noise Level dB(A) (1.5 m to 7 m): 60
Length (Without Handles and Wheels): N/A
Length (With Handles and Wheels): 1,198 mm (47.2 in.)
Width (Without Handles and Wheels): 539 mm (21.2 in.)
Width (With Handles and Wheels): 700 mm (27.6 in.)
Height (Without Lift-Hook): 721 mm (28.4 in.)
Height (With Lift-Hook): 821 mm (32.3 in.)
Dry Weight: 118.1 kg (260.4 lbs.)
Cold Climate Technology: Standard
