Features

• Powerful 1 HP 120V motor
• Adjustable upper/lower ball bearing blade guide system
• Large 21-3/8 x 15-5/8in tilting table with rack and pinion adjustment
• Flexible LED light increases workpiece visibility
• Belt tension adjustment knob
• Rack & pinion height adjustment system
• Circle cutting guide for diameters up to 27-1/2in
• Dust chute accepts 2, 3 and 4in dust collector hoses
• Comes complete with cast aluminum miter gauge, rip fence with 5in high face, push stick, adjustment wrench and hex. keys

Specifications

• cutting capacity frame to blade: 14in
• maximum depth of cut: 8-3/4in
• table size: 21-3/8 x 15-5/8in
• table height from floor: 40-1/2in
• blade size: 100-5/8 x (1/8 - 1in) x 0.025in
• motor: 1 hp
• amperage: 9.5 amp.
• Voltage: 120v, 1 phase, 60 Hz
• speeds: 2 (1476, 3280) SFPM
• assembled dimensions (LxWxH) / weight - 30 x 22-3/4 x 67-3/4in / 166 lbs
• packaging dimensions (LxWxH) / weight - 50-7/8 x 22-7/8 x 18-3/8in / 170 lbs
